solar reflective glass is produced by depositing one or more layers of nanoscale metal or (metal) compound thin films on float glass by magnetron sputtering under high vacuum. the main function of this film is to control the direct solar radiation and produce different visual effects and optothermal performance.
various shades of blue, green, blue green, silver grey and gold.
standards:
gb/t 18915.1 for coating glass standard
bs en 1096 european standard
r3221 japanese industrial standard
astmc 1376 american society of testing and materials
comfortable interior environment: effectively block the direct radiation of sunlight and ultraviolet rays, and create a comfortable interior space.
energy saving: products with different shading effects can reduce the costs of the air conditioning system to different degrees and achieve better return of investment.
colorfulness it can provide coated glass of various colors accord with design concept.
privacy: due to the reflection of the film, it is difficult to see the interior scene outside the building.
composite products: various composite glass processing products can be made by tempering, laminated, igu, hot bending and other composite processing
glass thickness: 3-19mm ( 1/8”~ 1/2”)
maximum size: 3300x18000mm ( 130”~511 4/5”)
minimum size: 300x800mm ( 11 4/5”~31 1/3”)
