the ultra-high performance low-e glass is a new low-e coated glass, be developed by combination with the upgrading of offline coating equipment and production process research, with high visible light transmission and low total solar transmission. at least three functional layers (e.g., silver) are superimposed in the film material, which has better spectral selectivity.
shgc is about 80% of double-silver low-e coated glass when similar visible light transmittance, further improving the sunshade performance of façade in summer.
it has lower visible light reflectivity and weakens the harmful light reflection effect of facade .
proper film material selection and structure design, some ultra high performance low-e glass can be off-site reprocessed.
glass thickness: 3-19mm ( 1/8”~ 1/2”)
maximum size: 3300x13000mm ( 130”~511 4/5”)
minimum size: 300x800mm ( 11 4/5”~31 1/3”)
